NCF211-32JE FYH 4 Bolt Flange Mounted Ball Bearing 2" Bore Dia., Concentric Collar

(No reviews yet) Write a Review
SKU:
NCF211-32JE
Condition:
New
  • NCF211-32JE FYH 4 Bolt Flange Mounted Ball Bearing 2" Bore Dia., Concentric Collar
$99.75

Description

NCF211-32E INFORMATION Concentric locking collar bearings utilize a special shaft locking mechanism that provides for 360 degrees of shaft contact and a high degree of ballpath roundness. This translates to low vibration and quiet operation. They are ideal for air handling applications and other areas with high speed operation. Re-greasable.



Product Specifications

BRANDFYH®

DYNAMIC LOAD RATING (N)43400

STATIC LOAD RATING (N)29400

LOCKING TYPEConcentric Collar

DUTYNormal

HOUSING MATERIALCast Iron

TEMPERATURE RANGE °F-4 To 212°F

BORE DIAMETER2

MANUFACTURERS PART NUMBERNCF21132E

MAX SPEED / OIL (RPM)2500 RPM

DESCRIPTIONFour-Bolt Flange Unit

TYPEMounted Ball Bearing

SHAFT DIAMETER2

BOLT SIZE INCHES5/8

STANDARD HOUSING NO.F211E

BEARING NO.NC21132

LENGTH6.38

INNER RINGWide

WIDTH6.38

HEIGHT2.36

BOLT SPACING MM130

For Bulk Orders Please Contact Cartney Bearing & Supply Co.
The product image shown may not represent actual product
